PowerSupply
The Power Supply for the Vision Controller has the following requirements:
- Voltage typical 3.3V (Max 3.6V, Min 1.7V)
- Maximum Current: 20mA
- Vision Controller Sleep current: 14uA
- Vision Controller typical operating current: 10mA
The power supply for the controller must be always available and may not switched off. If the fixture contains a battery the Vision controller should be supplied from the battery. This is necessary to support battery wake up from the NFC for example.
A block diagram of the schematic for the Vision Core Controller regarding power supply and state inputs may look like this:
